Intel Atom E3845(1.91G),17" flat panel

PPC-3170-RE4BE

Starting at $1,600.00

Main Features: 17" SXGA TFT LCD with resistive touchscreen Intel® Atom™ E3845 quad-core, 1.91 GHz, processor Fanless and Slim design Supports 1 x internal 2.5" SATA HDD, 1 x mSATA socket 1 x PCI/PCIe x 1 expansion slot Wide operating temperature range (-20°C ~ 60°C/-4° ~ 140°F) Wide range DC support (9 ~ 32 VDC) 1 x isolated RS-422/485 with automatic flow control and dual Intel GbE Optional GPIO (8 channels, TTL level)
PDF Document - PPC-3170-RE4BE Data Sheet
PPC-3170-RE4BE Data Sheet
(Size: 633.1 KB)
PDF Document - PPC-3170-RE4BE User Manual
PPC-3170-RE4BE User Manual
(Size: 19.4 MB)

System Configuration


* Selection required

PPC-3170-RE4BE
Your Configuration
PPC-3170-RE4BE Intel Atom E3845(1.91G),17" flat panel
Intel Atom E3845(1.91G),17" flat panel

In stock

Add to Favorites

$1,600.00

Don't see the exact configuration? Contact us, chat with us or give us a call 866-412-6278

PDF Document - PPC-3170-RE4BE Data Sheet
PPC-3170-RE4BE Data Sheet
(Size: 633.1 KB)
PDF Document - PPC-3170-RE4BE User Manual
PPC-3170-RE4BE User Manual
(Size: 19.4 MB)
Specifications
ManufacturerAdvantech
ProcessorIntel Atom E3845 quad core
Ethernet StandardI210
Video Port1x VGA 1x DP
Audio1 line out 1 speaker in
mSATA1x mSATA for storage
2.5" Drive1x 2.5" SATA for storage
Power Adapter90W recommended
Touchscreen Interface5 wire analog resitive
Vibrationsee manual
CPU Cores4
CPU FamilyIntel Atom
Base CPU SpeedUnder 2.0 Ghz
Brightness300-399 nit
Resolution1280 x 1024
Screen Size15.1-19"
Video OutputDisplay Port, VGA
LAN Ports1-4
Serial Ports3-4
USB 2.03-4
USB 3.01-2
Max Memory8 GB
Operating SystemWindows 7, Windows 10, Linux
Effective Memory Speed< 1600 HHz
Form FactorPanel PC
Native Storage Type2.5" SSD, mSATA Full
MountingWall Vesa
Memory1x SODIMM DDR3L 1333MHz
Display Type17" TFT LED panel
Display Size17"
Max Resolution1280 x 1024
Luminance350
Viewing Angle80 left 80 right 60 up 80 down
Backlight Lifetime50,000 hrs
Contrast Ratio800
Humidity10-95% @40C non condensing
Operating Temperature0-50C -20-60C with wide temp memory and drive
Storage Temperature-40-60C
Shocksee manual
EMCBSMI, CE, FCC Class A
Weight6.3KG unboxed
Dimension437 x 357 x 56.5mm
