ARS-2110: Railway Certified Intel Atom E3845 Fanless Box PC
ARS-2110 Series- Intel Atom Processor E3845
- Dual Independent Display: VGA and DVI
- M12 connector for Ethernet and USB interfaces MiniPCIe Expansions, Wi-Fi,
LTE, and GPS, RAID 0/1 Support (Expansion Slots) - EN50155 Compliant
- Power Input Range Covers 24V/72V/110V (±40%)
- TX Temperature Level:-40 ~ 70 °C (85 °C for 10 minutes) with EN45545
Compliant - EN50121 EMC Standards IEC61373 Body Mount Class B IP50 Rating
Frequently Asked Questions
The ARS-2110 uses an Intel® Atom™ E3845 quad-core processor with a max speed of 1.91GHz and 2MB L3 cache. It supports DDR3L 1600MHz 204-pin SODIMM memory, with 4GB installed by default and up to 8GB supported.
The ARS-2110 has one internal mSATA socket, with 32GB installed by default. An optional expansion module (AIO-SSD110-00A1E) adds a bay for 2 x 2.5" SSDs with DIO.
The ARS-2110 provides:
- Dual Ethernet: LAN1/LAN2, 10/100/1000 Mbps via Intel I210 controller, M12 A coded connectors (M12 X coded optional)
- USB: 1 x USB 3.0 (Type A), 2 x USB 2.0 (1 x Type A, 1 x M12)
- Serial: 2 x RS-232/422/485 ports with auto flow control
- Audio: Realtek ALC888S High Definition Audio with line-out, mic-in, line-in
- Display: VGA + DVI (dual display)
The ARS-2110 accepts DC power input of 24V, 72V, or 110V (±40%), depending on the ordered SKU. Power connects via an M12 connector with 4 poles.
The ARS-2110 is rated for an EN50155 TX operating temperature of -40 to 70°C (with a short-duration tolerance of 85°C for 10 minutes), and a storage temperature of -40 to 85°C. Relative humidity tolerance is 95% at 40°C (non-condensing).
Certifications include EN50155, EN50121, IEC61373 (railway), MIL-STD-810G (vibration/shock), CE/FCC Class A, BSMI (EMC), and UL, CB, BSMI (safety). It is also EN45545 compliant.
Yes. Optional modules include an Advantech 802.11abgn 2T2R Wide-Temp Wi-Fi module, an LTE/HSPA+/GPRS WWAN module, and GSM-R/GPRS-R support. GPS is optional with 50 channels, -160 dBm sensitivity, and A-GPS/Galileo capability. Any mini PCIe module can be integrated if the default Wi-Fi or WWAN function is not needed.
The ARS-2110 supports MiniPCIe expansions (for Wi-Fi, LTE, GPS) with RAID 0/1 support. Optional expansion I/O modules include CAN Bus, isolated serial port, isolated digital I/Os, and an expansion module for a 2 x 2.5" SSD drive bay.
The ARS-2110 supports Microsoft Windows 7, Windows 7 Embedded, Windows 10, and Linux Ubuntu 20.04. It also supports the Advantech SUSIAccess API.
The ARS-2110 measures 267 x 87.5 x 175 mm (W x H x D) and weighs 4.5 kg. It has an aluminum housing.
The ARS-2110 is available in three voltage variants, all using the Intel® E3845 processor, 4GB DDR3L, 32GB mSATA, VGA, DVI, dual LAN, dual COM, dual USB, and audio:
- ARS-2112TX-10A1E — 24V
- ARS-2112TX-30A1E — 72V
- ARS-2112TX-40A1E — 110V
How-to Guides
- Order the optional AIO-SSD110-00A1E single SSD carrier module, which adds a drive bay with DIO support for the ARS-2110.
- Alternatively, order the expansion I/O module that provides a bay for 2 x 2.5" SSD drives.
- Install the SSD(s) into the carrier/expansion module per the module's mounting points.
- Connect the module to the ARS-2110's internal mSATA/expansion interface as documented for the chosen module.
- Confirm the DC voltage rating of your unit (24V, 72V, or 110V ±40%) matches your power source.
- Use the M12 A coded power connector on the unit for power input.
- For bench testing or wiring to a terminal block, use the optional FRU-ITAPWR-003 M12 A coded power-to-terminal-block cable.
- Identify the M12 A coded connectors on the unit for LAN1/LAN2 (10/100/1000 Mbps) and the M12 USB 2.0 port.
- Use the optional FRU-ITALAN-004 M12 A coded to RJ45 cable to connect standard Ethernet cabling to the LAN M12 port.
- Use the optional FRU-ITAUSB-0002 M12 A coded to USB Type-A cable to connect standard USB devices to the M12 USB port.
| Product Available On | May 31, 2030 |
|---|---|
| Manufacturer | Advantech |
| Short Description | The ARS-2110 is a dedicated box computer for railway. ARS-2110 combines various I/O connectors which can be connected to devices such as LED displays (PIDS, Passenger Information Display Systems). |
