NVIDIA JETSON
Generative AI at the Edge
NVIDIA JETSON COMPUTERS
NVIDIA Jetson is a complete System on Module (SOM) that includes GPU, CPU, memory, power management, high-speed interfaces. Multiple module models are available with various features and in rugged fanless formats from CoastIPC.
Contact us today to find the right NVIDIA Jetson solution to fit your needs.
What's Jetson?
A fast low-power alternative to traditional computing platforms, Jetson brings high-speed data collection, analysis, and action to any location, from the factory floor to the far edge where systems can be most efficient.
What About x86?
You don’t have to choose between the power of x86 and Jetson. Add in powerful AI and machine learning computational power to your industrial machines by adding a Jetson expansion card. Get the tensor cores you need with none of the compromise.
Orin vs Xavier
Orin is the latest and most powerful version of the Jetson platform. For the most advanced applications and high data instances, Orin is the right choice for top speed and power efficiency.
Xavier is the powerful and efficient choice to process data and execute action on the edge. Designed for next generation robotics and autonomous action, Xavier is now found in thousands of applications in multiple environments.
NVIDIA Jetson Computers
NRU-230V-240S-AWP: IP66 Waterproof AGX Orin Computer with 8x GMSL2, 4x PoE+ GbE, and 1x 10GbE Ports
NRU-230V-240S-AWP Series- NVIDIA Jetson AGX Orin SoM bundled with JetPack 5.1.1
- NVIDIA Jetson AGX Orin Industrial bundled with JetPack 6.0
- Rugged -25°C to 70°C fanless operation (JAO32/JAO64)
- No throttling at 55°C with JAO64 MAXN Mode
- Rugged -40°C to 75°C fanless operation (JAOi)
- No throttling at 55°C with JAO64 MAXN Mode
- IP66 waterproof and dustproof
- -25°C to 70°C fanless operation
- Support 8x GMSL2 FAKRA Z automotive cameras (NRU-230V-AWP)
- 4x PoE+ GbE and 1x 10GBASE-T via M12 X-coded connectors
- 2x isolated CAN 2.0, 1x RS232, and 1x isolated RS485 via M12 A-coded connectors
- 1x system monitoring port by automotive-grade MCU
- 8V to 48V wide-range DC input with built-in ignition power control
Learn More
NRU-230V-240S-AWP Series Data Sheet (Size: 759.3 KB)
NRU-230V-240S-AWP Series User Manual (Size: 3.9 MB)Starting at $3,545.00
PCIe-NX156U3: NVIDIA Jetson Orin NX 100 TOPS Intelligent Frame Grabber Card with 6x USB 3.2 Ports
PCIe-NX156U3- Powered by NVIDIA Jetson Orin NX bundled with JetPack 5.1
- Single-slot width, standard PCIe half-length card form factor
- 6x USB 3.2 ports, each port with user-configurable 900mA and 1500mA current limit
- 100 TOPS AI inference performance
- Software-programmable per-port power on/off control
- 1x isolated RS-485 and 1x RS-232
- x1 Gen2 PCI Express interface offering 2.5Gb/s total bandwidth
- -25°C to 60°C operating temperature with airflow
PCIe-NX156U3 Data Sheet (Size: 1.1 MB)Starting at $1,425.00
PCIe-NX154PoE: NVIDIA Jetson Orin NX 100 TOPS Intelligent Frame Grabber Card with 4x PoE+ Ports
PCIe-NX154PoE- Powered by NVIDIA® Jetson Orin™ NX bundled with JetPack 5.1
- Single-slot half-length PCIe card form factor
- 4x PoE+ 2.5 GbE ports with a 50W total power budget
- 100 TOPS AI inference performance capable of up to four simultaneous streams of 4K@30FPS video decoding
- 1x isolated RS-485 and 1x RS-232
- x1 Gen2 PCI Express interface offering 2.5Gb/s total bandwidth
- -25°C to 60°C operating temperature with airflow
PCIe-NX154PoE Data Sheet (Size: 455.6 KB)Starting at $1,500.00
PCIe-GL26: NVIDIA Jetson Xavier NX AI-Enabled 6-Port GMSL2 Camera Frame Grabber Card
PCIe-GL26- 6x GMSL2 FAKRA Z inputs supporting automotive GMSL2 cameras
- Turnkey solution with pre-installed GMSL2 camera driver for selected cameras
- Powered by NVIDIA® Jetson Xavier™ NX bundled with JetPack 4.6.1
- 21 TOPS AI performance with up to 22 streams simultaneous 1080p@30FPS video encoding capability
- x2 Gen3 PCI Express interface offering 10Gb/s total bandwidth
- 1x GPS PPS input for frame sync calibration
- 1x isolated CAN 2.0 and 1x RS232
- -25°C to 60°C operating temperature with airflow
PCIE-GL26 Data Sheet (Size: 366.8 KB)PCIE-GL26 User Manual (Size: 1.7 MB)Starting at $2,725.00
NVIDIA Jetson Nano Developer Kit
MIC-710AIL-DVA1Main Features
NVIDIA® Jetson Nano™ embedded
- 1 x M.2 2280 NVMe for storage
- 1 x Mini PCIe for expansion
- Linux OS with BSP (board support package)
- Supports deep learning trained models
MIC-710AIL-DVA Data Sheet (Size: 1.7 MB)Starting at $495.00
NRU-52S/52S+ Rugged NVIDIA Jetson Orin/Xavier NX Edge AI Computer
NRU-52S SeriesMain Features
- Powered by NVIDA Jetson Orin or Xavier NX SOM bundled with JetPack
- Ruggesd -25-70C fanless operation
- 4x IEEE 802.3bt PoE++ GbE ports with screw-lock
- 2x mini-PCIe sockets for WiFi/GNSS/NVMe/CAN modules
- 1x 3042/3052 M.2 B key socket for 4G/5G mobile communication
- 1x hardware configurable RS232/422/485 port
- 8V-35V wide range DC imput with built-in ignition power control
- MIL-STD-810G and EN 50155 certified
NRU-52S Data Sheet (Size: 774.6 KB)NRU-52S User Manual (Size: 2.8 MB)Starting at $1,525.00
NRU-51V+/51V: Rugged NVIDIA Jetson Orin NX/Xavier NX GMSL2 Camera Sensor Hub for Autonomous Vehicles and Teleoperation
NRU-51V+/NRU-51V- Powered by NVIDIA Jetson Orin NX or Xavier NX SOM bundled with JetPack 5.1.1
- Rugged -25°C to 60°C fanless operation
- Support 4x GMSL2 automotive cameras via FAKRA Z connectors
- 1x 10GBASE-T 10Gb and 1x 1GBASE-T 1Gb Ethernet port
- 2x mini-PCIe sockets for WiFi/GNSS/NVMe/CAN modules
- 1x M.2 3042/ 3052 B key socket for 4G/5G mobile communication
- 1x isolated CAN 2.0, 1x configurable RS232/422/485 port, and 1x GPS PPS input
- 8V to 35V wide-range DC input with built-in ignition power control
NRU-51V+/51V Data Sheet (Size: 1.6 MB)NRU-51V+/51V User Manual (Size: 3 MB)Starting at $1,750.00
NRU-220S NVIDIA Jetson AGX Orin AI NVR for Intelligent Video Analytics
NRU-220S- NVIDIA Jetson AGX Orin SoM bundled with JetPack 5.1.1
- NVIDIA Jetson AGX Orin Industrial bundled with JetPack 6.0
- Rugged -25°C to 70°C fanless operation (JAO32/ JAO64)
- No throttling at 65°C with JAO64 MAXN Mode
- Rugged -40°C to 75°C fanless operation (JAOi)
- No throttling at 75°C with JAOi 35W Mode
- 2x 2.5 Gigabit Ethernet + 4x IEEE 802.3at Gigabit PoE+ ports
- 2x front-accessible 2.5” SSD trays
- 1x M.2 2280 M key socket for NVMe SSD
- 2x mini-PCIe sockets for WiFi/ GNSS/ NVMe/ CAN modules
- 1x 3042/ 3052 M.2 B key socket for 4G/5G mobile communication
- 1x isolated RS-485 and 2x RS232 ports
- 8V to 48V wide-range DC input with built-in ignition power control
NRU-220S Data Sheet (Size: 988.3 KB)NRU-220S User Manual (Size: 3 MB)Starting at $2,995.00
NRU-156U3-FT: NVIDIA Jetson Orin NX Edge AI Computer with 6x USB 3.2 Ports
NRU-156U3-FT- Powered by NVIDIA Jetson Orin NX bundled with JetPack 5.1
- Flat-top heatsink design for conduction-cooled, in-cabinet deployment
- Up to 100 TOPS AI inference performance
- 6x USB 3.2 full-bandwidth ports for camera connectivity
- 1x RS-232 and 1x isolated RS-485
- 1x M.2 2242 M key NVMe for BSP and data storage
- -25°C to 60°C fanless operating temperature (with heat spreader attachment.
- No throttling at 60°C (with Orin NX 20W TDP mode)
NRU-156U3-FT Data Sheet (Size: 1.1 MB)NRU-156U3-FT User Manual (Size: 1.9 MB)Starting at $1,445.00
NRU-154PoE-FT: NVIDIA Jetson Orin NX Edge AI Computer with 4x 2.5GbE PoE+
NRU-154PoE-FT- Powered by NVIDIA Jetson Orin NX bundled with JetPack 5.1
- Flat-top heatsink design for conduction-cooled, in-cabinet deployment
- Up to 100 TOPS AI inference performance
- 4x 2.5GbE PoE+ full-bandwidth ports for camera connectivity
- 1x RS-232 and 1x isolated RS-485
- 1x M.2 2242 M key NVMe for BSP and data storage
- -25°C to 60°C fanless operating temperature (with heat spreader attachment.
- No throttling at 60°C (with Orin NX 20W TDP mode)
NRU-154PoE-FT Data Sheet (Size: 1.1 MB)NRU-154PoE-FT User Manual (Size: 1.9 MB)Starting at $1,525.00
NRU-120S NVIDIA Jetson AGX Xavier AI Platform
NRU-120S- Powered by NVIDIA Jetson AGX Xavier SOM bundled with JetPack 4.4
- 4x IEEE 802.3at Gigabit PoE+ ports with screw lock
- 2x front-accessible, hot swappable 2.5" HDD/SSD trays
- 1x mini-PCIe socket for WiFi/4G module
- 1x isolated CAN bus port and 1x RS-232 port with flow control
- 1x GPS PPS input, 3-CH isolated DI and 4-CH isolated DO
- 8~35V wide-range DC input with built-in ignition power control
NRU-120S Data Sheet (Size: 676.4 KB)NRU-120S User Manual (Size: 3.8 MB)Starting at $2,715.00
NRU-110V NVIDIA Jetson AGX Xavier Edge AI Platform Supporting 8x GMSL Cameras and 10GbE Ethernet
NRU-110V Series- Powered by NVIDIA Jetson AGX Xavier SOM bundled with JetPack 4.4
- Support up to 8x GMSL automotive cameras via FAKRA Z connectors
- 1x 10 GBASE-T 10G Ethernet port
- 1x M.2 2280 M key socket for NVMe SSD
- 1x miniPCIe socket for WiFi/4G module
- 1x Isolated CAN bus port and 1x RS-232 port with flow control
- 1x GPS PPS input, 3-CH isolated DI and 4-CH isolated DO
- 8V to 35V wide-range DC imnput with built-in ignition power control
NRU-110V Data Sheet (Size: 639.9 KB)NRU-110V User Manual (Size: 3.8 MB)Starting at $3,130.00
MIC-733-AO AI Inference System based on NVIDIA Jetson AGX Orin
MIC-733-AO- Fanless compact design
- Embedded with NVIDIA® Jetson AGX Orin™ up to 275 TOPS
- Support 4x GbE (optional PoE), 4 x USB 3.2 Gen2 (10Gbit/s)
- Support 2 x mPCIe, 2 x Nano SIM slot
- Support 4x GbE (optional PoE, IEEE 802.3af/at)
- Support PCIex8 add on card by iModule
- Support Allxon 24/7 remote monitoring and OTA deployment; Azure Certified Devices
MIC-733-AO Data Sheet (Size: 1.1 MB)MIC-733-AO User Manual (Size: 6.1 MB)Starting at $3,375.00
MIC-732-AO: AI Inference System Based on NVIDIA Isaac Nova Orin
MIC-732-AO- Fanless and ultra-compact design
- Embedded with NVIDIA® Jetson AGX Orin™ up to 275 TOPS
- Supports 1 x 10GbE, 1 x 1GbE, 3 x USB 3.2 Gen 2 (10 Gbit/s)
- Supports 2 x CANbus, 1 x mPCIe, 2 x Nano SIM slots
- Support Total 8-ch GMSL3.0/2.0 with FAKRA connectors
- Support NVIDIA Isaac Robot Operating System (ROS2)
MIC-732-AO Data Sheet (Size: 698.9 KB)Coming Soon
Learn More
MIC-730IVA 8CH Video Recorder with NVIDIA Jetson AGX Xavier
MIC-730IVA- NVIDIA Jetson Xavier NX embedded
- Support 8CH PoE video Input
- Supports 2x 2.5"/3.5" drives
- Bundled with Linux Ubuntu 18.04 with BSP
- Low power consumption
- H.264/H.265 camera supported
- Jetpack 4.2.2 compatible
MIC-730IVA Data Sheet (Size: 1.2 MB)Starting at $3,645.00
MIC-730AI Inference System with NVIDIA Jetson AGX Xavier
MIC-730AI- Fanless compact design
- NVIDIA Jetson Xavier NX embedded
- Supports 1x mPCIe and 1x M.2 (PCIex4 NVMe)
- 2x LAN ports
- Bundle with Linux 18.04
- Low power consumption
- Support PCIe add on card
- Supports 24/7 secure remote monitoring, control, and OTA deployment - powered by Allxon (support JetPack 4.4GA and above)
MIC-730AI Data Sheet (Size: 1.1 MB)Starting at $3,645.00
MIC-717-OX: AI NVR Solution with NVIDIA Metropolis Microservices on Jetson Orin
MIC-717-OX- Compact fan design
- Embedded NVIDIA® Jetson Orin™ NX capable of up to 100 TOPS
- Support 1 x 3.5" SATA HDD, or 1 x 2.5" SSD
- Integrated with NVIDIA Metropolis Microservices on Jetson
- Supports Allxon 24/7 remote monitoring and OTA deployment
MIC-717-OX Data Sheet (Size: 862.5 KB)Coming Soon
Learn More
MIC-715-OX Ruggedized In-Vehicle AI Fanless System Based on NVIDIA Jetson Orin NX
MIC-715-OX- Ruggedized IP67 waterproof fanless design
- Embedded with NVIDIA Jetson Orin NX up to 100 TOPS
- 2 x GbE and 4 x PoE with IEEE 802.3af compliance
- 2 x USB 3.0, 1 x CANbus, 1 x HDMI
- Supports 2 x mPCIe, 1 x M.2 3052, 1 x M.2 2280
- Supports Allxon 24/7 remote monitoring and OTA deployment
Learn More
MIC-715-OX Data Sheet (Size: 1.2 MB)Starting at $3,175.00
MIC-715 AI Inference System Based on NVIDIA Jetson Xavier NX
MIC-715Main Features
- Compact, IP67 rated, waterproof fanless design
- Embedded NVIDIA® Jetson™ Xavier NX
- Supports 4 x IEEE 802.3af compliant PoE
- Linux OS with board support package (BSP)
- Supports deep learning trained models
- Supports wide operating temperature range
MIC-715-NX Data Sheet (Size: 1.2 MB)MIC-715-NX User Manual (Size: 9.9 MB)Starting at $2,995.00
MIC-713S: AI Solution Kit Based on NVIDIA Jetson Orin Nano and NX
MIC-713S- Open-frame solution kit design
- Embedded with NVIDIA Jetson Orin NX up to 100 TOPS
- Supports 5 x GbE, 6 x USB 3.2 Gen 2
- Supports 1 x mPCIe, 1 x M.2 3052, 1 x M.2 2280
- Supports Allxon 24/7 remote monitoring and OTA deployment
MIC-713S-OX Data Sheet (Size: 1.7 MB)MIC-713S-ON Data Sheet (Size: 1.7 MB)Starting at $975.00
MIC-713-OX AI Platform Based on NVIDIA Jetson Orin NX
MIC-713-OX Series- Compact fanless design
- Embedded NVIDIA® Jetson Orin™ NX up to 100 TOPS
- Supports 2 x GbE, 6 x USB 3.2 Gen 2
- Supports 1 x mPCIe, 1 x M.2 3052, 1 x M.2 2280
- Supports Allxon 24/7 remote monitoring and OTA deployment
MIC-713-OX Data Sheet (Size: 1.1 MB)Starting at $1,695.00
MIC-711-OX AI Inference System Based on NVIDIA Jetson Orin NX
MIC-711-OX Series- Fanless and ultra-compact design
- Embedded with NVIDIA Jetson Orin NX up to 100 TOPS
- Includes 128GB Standard Temp Commercial NVMe M.2
- Supports 1 x GbE, 2 x USB3.2 Gen1 (5Gbit/s)
- Supports 1 x mPCIe, 1 x M.2 3052, 1 x M.2 2280
- Supports Allxon 24/7 remote monitoring and OTA deployment
MIC-711-OX Data Sheet (Size: 857.3 KB)MIC-711-OX User Manual (Size: 5.1 MB)Starting at $1,425.00
MIC-711-ON AI Inference System Based on NVIDIA Jetson Orin Nano
MIC-711-ON Series- Fanless and ultra-compact design
- Embedded with NVIDIA Jetson Orin Nano up to 40 TOPS
- Includes 128GB Standard Temp Commercial NVMe M.2
- Supports 1 x GbE, 2 x USB 3.2 Gen 1 (5 Gbit/s)
- Supports 1 x mPCIe, 1 x M.2 3052, 1 x M.2 2280
- Supports Allxon 24/7 remote monitoring and OTA deployment
MIC-711-ON Data Sheet (Size: 715.6 KB)Starting at $895.00
MIC-710IVX 8CH Video System with NVIDIA Xavier NX
MIC-710IVX- NVIDIA Jetson Xavier NX embedded
- Support 8CH PoE video Input
- Supports 2x 2.5"/3.5" drives
- Bundled with Linux Ubuntu 18.04 with BSP
- Low power consumption
- H.264/H.265 camera supported
MIC-710IVX Data Sheet (Size: 1 MB)Starting at $1,995.00
MIC-710IVA 8CH Video system with NVIDIA Jetson NANO
MIC-710IVA- NVIDIA Jetson NANO embedded
- Support 8CH PoE video Input
- Bundled with Linux Ubuntu 18.04 with BSP
- Low power consumption
- H.264/H.265 camera supported
MIC-710IVA Data Sheet (Size: 1 MB)Starting at $865.00
MIC-710AIX Inference System with NVIDIA Jetson Xavier NX
MIC-710AIX- Fanless compact design
- NVIDIA Jetson Xavier NX embedded
- 2x LAN ports
- Linux OS with BSP (board support package)
- Supports deep learning trained models
- Wide operating temperature range
- Supports 24/7 secure remote monitoring, control, and OTA deployment - powered by Allxon
MIC-710AIX Data Sheet (Size: 1.3 MB)MIC-710AIX User Manual (Size: 3.4 MB)Starting at $1,625.00
MIC-710AI Inference System with NVIDIA Jetson NANO
MIC-710AI- Fanless compact design
- NVIDIA Jetson Xavier NX embedded
- 2x LAN ports
- Linux OS with BSP (board support package)
- Supports deep learning trained models
- Wide operating temperature range
- Supports 24/7 secure remote monitoring, control, and OTA deployment - powered by Allxon
MIC-710AI User Manual (Size: 3.4 MB)MIC-710AI Data Sheet (Size: 1.2 MB)Starting at $740.00
ITA-560NX: Railway Certified Jetson Orin NX Rugged Computer
ITA-560NX- Fanless box computer designed for AI inference
- Embedded NVIDIA Jetson Orin NX platform
- Compliant with EN 50155 OT 1 and EN 5021-3-2 EMC standards
- Rugged M12 connectors suitable for harsh, industrial environments
- 1x mPCIe. 1x M.2 E-key. 1x M.2 M-key, 1x M.2 B-key for easy expansion
- Bundled with Linux Ubuntu 20.04
Learn MoreITA-560NX Data Sheet (Size: 772 KB)Starting at $2,995.00
ITA-510NX: Railway Certified AI Inference System Powered by NVIDIA Jetson Orin NX
ITA-510NX Series- Fanless system designed for AI inference
- Embedded NVIDIA Jetson Orin NX platform
- Compliant with EN 50155 OT1 and EN 50121-3-2 EMC standards
- Rugged M12 connectors suitable for harsh, industrial environments
- 1 x Mini PCIe, 1 x M.2 (E-key),1 x M.2 (M-key) and 1 x M.2 (B-key) for easy
expansion - Bundled with Linux Ubuntu 20.04 operating system
Learn MoreITA-510NX Data Sheet (Size: 1.1 MB)Coming Soon
Learn More
AIR-030: AI Inference System Based on NVIDIA Jetson AGX Orin
AIR-030- Compact and high-performance AI box up to 275 TOPS AI computing
- NVIDIA Jetson AGX Orin 32G/64G built-in
- 9~36V wide power and -10~60 °C wide temp. supported
- Multiple IO ports: 3 x LAN, DIO, 4x COM, 4x USB 3.2 and USB type C
- Support various expansions 1 x M.2 2280(NVME), 1 x M.2 2230 and 1 x PCIe x 16 (optional)
- Pre-load Ubuntu 20.04 image, JetPack 5.0 SDK
- IEC 61000-6-4 Heavy Industry Certificate
- AWS Greengrass Certified
AIR-030 Data Sheet (Size: 1.8 MB)AIR-030 User Manual (Size: 23.4 MB)Starting at $4,200.00
AIR-020X: AI Inference System with NVIDIA Jetson Xavier NX
AIR-020X- Extreme Compact and performance AI box up to 21 TOPS AI computing
- NVIDIA Jetson Xavier NX built-in
- 12~24V wide power and -10~55 °C wide temp. supported
- Multiple IO ports: Dual LAN, DIO, 2x COM, 2x USB 3.2 and USB type C
- M.2 2280 128GB storage built-in
- Edge AI Suite AI Utility Support for pre-trained models and deep learning
- Linux Ubuntu 18.04 LTS and JetPack 4.5.1 preload
- IP40 Design compliance
- Qualified for Edge AI SRP of WISE-DeviceOn
AIR-020X Data Sheet (Size: 2.5 MB)Starting at $1,600.00
AI Inference System (Lite) based on NVIDIA® Jetson Nano™/ Xavier™ NX
MIC-710AILMain Features
- Fanless and ultra-compact design
- NVIDIA Jetson Nano/ Xavier NX embedded
- 1 x M.2 2280 NVMe for storage
- Linux OS with BSP (board support package)
- Supports deep learning trained models
- Wide-operating temperature range
MIC-710AIL Data Sheet (Size: 1 MB)Starting at $545.00
