Intel Core Ultra Series 2
In the era of AI, Intel Core Ultra processors scale performance to a new level. From digital security in smart cities to automation on the factory floor, Intel Ultra Series 2 supercharges your edge computing applications. Enable edge AI and machine learning in more places—wherever your business needs to be.
Contact us today to find the right Intel Ultra solution to fit your project's needs.
Ultra Performance
Intel Core Ultra processors integrate high-performance CPU, GPU, and NPU engines into a unified platform built to meet the rigorous demands of industrial computing. With up to 99 TOPS of compute power, this architecture enables scalable solutions across manufacturing, energy, transportation, and other industrial environments.
Multilayer Security
Protect your users, data, and business with AI-enhanced threat detection, data and application protection, and above and below-the-OS security. Remotely power up, update, and repair PCs outside of the firewall to provide user help from virtually anywhere.
AI for the Edge
Deploy your edge solutions with advanced AI and graphics performance in power-efficient packaging. Enhance your edge device designs with greater flexibility and efficiency by leveraging a 12–65W TDP range. Available comprehensive long-term software support helps maximize deployment value and extend device longevity.
Intel Core Ultra Series 2
Nuvo-11000: Intel Core Ultra 200 Series Fanless Embedded Computer with 2.5GbE/GbE, USB 3.2, 8-CH DIO, Optional 10GbE, Expansion Cassette, and MezIO
Nuvo-11000 Series- Intel Core Ultra 200 Series 24C/24T 35W/65W LGA1851 CPU
- Rugged, -25°C to 70°C fanless operation
- Up to 5x 2.5GbE and 1x GigE ports with optional PoE+
- Supporting 9.5 KB jumbo frame
- Up to 8x USB 3.2 Gen2 ports
- 4-CH isolated DI and 4-CH isolated DO
- 1x optional 10GBASE-T Ethernet
- Expansion Cassette for PCIe add-on card accommodation
- MezIO interface for easy function expansion
Nuvo-11000 Data Sheet (Size: 960.5 KB)
Coming Soon
Learn More
Nuvo-11531: Intel Core Ultra 200 Compact Fanless Computer with 4x PoE+ 2.5GbE, 4x USB 3.2, 1x Swappable 2.5” SSD Tray, and 1x External SlimSAS Connector
Nuvo-11531 Series- 212 x 165 x 63 mm low-profile design
- Intel Core Ultra 200 series 35W/ 65W LGA1851 CPU
- Rugged, -25°C to 60°C fanless operation
- Up to 48GB DDR5 6400 memory
- 4x 2.5GbE with optional PoE+ and 4x USB3.2 Gen1 with screw-lock
- 1x M.2 2280 Gen4x4 NVMe and 1x swappable 2.5” SSD tray for storage
- 1x PCIe Gen4x8 via SlimSAS 8i (SFF-8654) connector (Nuvo-11588 only)
- 8V to 48V wide-range DC input with optional ignition power control
Nuvo-11531 Data Sheet (Size: 1.1 MB)Coming Soon
Learn More
MIC-780: Compact Fanless System with Intel Core Ultra 5/7/9 Processors (Series 2)
MIC-780 Series- Intel Core Ultra 5/7/9 Processors (Series 2)
- CPU Type: Socket (LGA1851)
- Chipset: Intel W880/H810
- DDR5 Memory Up to 96GB 6400MT/s
- MIC-780W: 3 x displays – 2 x HDMI/1 x DP, 4 x GbE LAN, 4 x USB 3.2 Gen2x1 (10G), 2 x COM, 1 x NVMe M.2 (PCIe Gen4 x4)
- MIC-780H: 3 x displays – 2 x HDMI/1 x DP, 2 x GbE LAN, 2 x USB 3.2 Gen 2x1 (10G), 2 x USB 3.2 Gen 1x1 (5G) , 2 x COM
Coming Soon
Learn More
ASMB-789: LGA1851 Intel Core Ultra 9/7/5 ATX with 4x DDR5, 5xPCIe, 7xUSB 3.2, 4xSATA3, Quad/Dual LAN
ASMB-789- LGA 1851 Intel Core Ultra 9/7/5 processors with W880 chipset
- DDR5 ECC/Non-ECC 5600/4800/4400/MT/s UDIMM up to 192 GB
- one PCIe x 16 (Gen5), one PCIe x 8 (Gen5) and five PCIe x 4 slots
- Triple displays - DP, VGA, and HDMI 2.0 ports
- Four SATA 3 ports and seven USB 3.2 ports
- One M.2 2280 (PCIe x4)
- Rackmount optimized placement with positive air flow design
- 0 ~ 60 °C (32 ~ 140 °F) ambient operating temperature range
ASMB-789 Data Sheet (Size: 980.9 KB)Coming Soon
Learn More
AIMB-789: LGA1851 Intel Core Ultra 9/7/5 ATX with HDMI/VGA, DDR5, USB 3.2, 6 COMs
AIMB-789- Intel Core Ultra 9/7/5 processor with Q870 chipset
- Four DIMM sockets up to 192GB DDR5 5600
- Triple display DP/HDMI/VGA and dual GbE LAN
- M.2, SATA RAID 0, 1, 5, 10, USB 3.2 Gen 2
- iBMC remote out-of-band power management on DeviceOn
- Legacy platform is not supported
- dTPM 2.0 module is required to enable Intel vPro and TPM
- Intel Platform Trust Technology (Intel PTT) ready for Win 11
AIMB-789 Data Sheet (Size: 980.1 KB)AIMB-789 Startup Manual (Size: 1.7 MB)Coming Soon
Learn More
ASMB-589: LGA1851 Intel Core Ultra 9/7/5 MicroATX with 4x DDR5, 4xPCIe, 8xUSB 3.2, 5xSATA3, Quad/Dual LAN
ASMB-589- LGA 1851 Intel Core Ultra 9/7/5 processors with W880 chipset
- DDR5 ECC/Non-ECC 5600*/4800/4400/ MT/s UDIMM up to 192 GB
- One PCIe x16 (Gen 5), one PCIe x4 (Gen 5) and two PCIe x4 (Gen 4) slots
- Triple displays - DP, VGA, and HDMI 2.0 ports
- Five SATA 3 ports and eight USB 3.2 ports
- One M.2 2280 (PCIe x4)
- Rackmount optimized placement with positive air flow design
- 0 ~ 60 °C (32 ~ 140 °F) ambient operating temperature range
- Supports Windows 10/11 (64-bit) and Server 2022 (64-bit)
ASMB-589 Data Sheet (Size: 1.1 MB)Coming Soon
Learn More
