15" XGA Ind. Monitor w/ Resistive TS (C

FPM-5151G-R3BE

This product is no longer available.

An Alternative Product May Be Available!

Contact us for more information at 866-412-6278 or enter your information below.

Main Features:

  • 15" XGA TFT LCD LED backlight
  • Direct VGA & DVI-D input interface
  • Lockable OSD keys with 2 user-defined contrast/brightness settings
  • Flat-sealed front panel
  • Robust design with anti-rust chassis and aluminum die-cast front panel
  • Front accessible USB connector
  • Combo RS-232 & USB interface for touchscreen function (optional)
  • Supports industrial 10-30 VDC power input with Phoenix jack
  • Supports panel, wall, desktop, rack or VESA arm mounting
  • Front panel is IP65 compliant
PDF Document - FPM-5151G-R3BE Datasheet
FPM-5151G-R3BE Datasheet
(Size: 508.7 KB)

The FPM-5000G series comprises 15", 17", and 19" flat-panel color monitors with LED backlights that provide an ample display area and sharp, vivid images. Specifically designed for industrial applications, these monitors support Direct VGA and DVI-D signal transmissions, which allow VGA control cards to be integrated in the system. The onscreen display output can be adjusted using two user-defined function keys. The front-accessible USB connector provides easy access to the controller, while the wide-range (10 ~ 30 VDC) power support makes these monitors ideal for factory and machine automation display applications.

PDF Document - FPM-5151G-R3BE Datasheet
FPM-5151G-R3BE Datasheet
(Size: 508.7 KB)
Specifications
ManufacturerAdvantech
Brightness400+ nit
Resolution1024 x 768
Screen Size10.1-15"
Video OutputDVI-D, VGA
Operating SystemWindows 7, Windows 10, Linux
CertificationBSMI, CCC, CE, FCC Class A, UL
Enclosure

Front panel: Aluminum and flat-sealed. Rear cover: Anti-rust coating

MountingPanel, wall, desktop, VESA arm, or 19" rackmount
Display Type15" XGA
Display Size15"
Max Resolution1024 x 768
Max Colors16.7 M
Luminance400
Viewing Angle160/140
Backlight Lifetime50,000 Hours
Contrast Ratio700:1
Light Transmission

> 80%

Type5-wire resistive
Humidity

10 ~ 90% non-condensing

Operating Temperature0°C ~ 50°C (32°F ~ 122°F)
Storage Temperature-20°C ~ 60°C (-4°F ~ 140°F)
Power Input Voltage10-30v
Power Consumption18 W + 20%
OS SupportWindows XP, Vista,7, 8,10,XPe and Linux
Weight 6kg
Dimension 449.92mm x 315.63mm x 50.5 mm (17.71 x 12.43 x 1.99 in)
