Neousys 6th Generation Intel Skylake Core‚ Fanless Controller

Nuvo-5026 E

Starting at $1,470.00

Main Features:

  • Intel® 6th Gen Core™ i7/i5/i3 LGA1151 35W/65W
  • Dual PCIe x8 slots in patented expansion Cassette
  • MezIO™ interface for easy function expansion
  • Rugged, wide temperature range from -25°C to 70°C fanless operation
  • 6x GbE ports, supporting 9.5 KB jumbo frame
  • Up to 32 GB, DDR4-2133 SODIMM
  • Accommodates two 2.5" SATA HDD/ SSD with RAID 0/1 support
  • VGA/ DVI/ DP triple independent display, supporting 4K/2K resolution



PDF Document - Nuvo-5026E Data Sheet
Nuvo-5026E Data Sheet
(Size: 458.6 KB)
PDF Document - MezIO Compatibility Chart
MezIO Compatibility Chart
(Size: 791.1 KB)

System Configuration


* Selection required

Your Configuration
Nuvo-5026 E Neousys 6th Generation Intel Skylake Core‚ Fanless Controller
Neousys 6th Generation Intel Skylake Core‚ Fanless Controller

In stock

Add to Favorites

$1,470.00

Don't see the exact configuration? Contact us, chat with us or give us a call 866-412-6278

Nuvo-5026E is a member of the Nuvo-5000 family with dual PCIe slots. The dual PCIe slots enhance expansion abilities while preserving all practical features such as ruggedness, performance and versatility. The expandability makes Nuvo-5026E more adaptable to various application needs while the two PCle slots in the patented expansion Cassette are easy to access for PCIe card installation without the need to disassemble the system. Nuvo-5026E supports LGA1151 6th-Gen Core™ processors. It offers processor selection flexibility from Core™ i7 to Celeron according to performance needs and operating environment. It also offers plenty of I/O functions such as 6x GbE, 4x USB3.0, 3x COM ports and triple independent display support. In addition, Neousys’ MezIO™ interface can also further expand system I/Os offering up to either 11x COM ports, 10x GbE, 8x USB3.0, 32x DIO or ignition power control by installing an optional MezIO™ module. Nuvo-5026E is an expandable and flexible platform with numerous I/O functions for various industrial applications
PDF Document - Nuvo-5026E Data Sheet
Nuvo-5026E Data Sheet
(Size: 458.6 KB)
PDF Document - MezIO Compatibility Chart
MezIO Compatibility Chart
(Size: 791.1 KB)
Specifications
ManufacturerNeousys
ProcessorIntel® Core™ i7-6700 (8M Cache,3.4/ 4.0 GHz, 65W TDP)|Intel® Core™ i5-6500 (6M Cache, 3.2/ 3.6 GHz, 65W TDP)|Intel® Core™ i3-6100 (3M Cache, 3.7 GHz, 51W TDP)|Intel® Pentium® G4400 (3M Cache, 3.3 GHz, 54W TDP)|Intel® Celeron® G3900 (2M Cache, 2.8 GHz, 51W TDP)|Intel® Core™ i7-6700TE (8M Cache, 2.4/ 3.4 GHz, 35W TDP)|Intel® Core™ i5-6500TE (6M Cache, 2.3/ 3.3 GHz, 35W TDP)|Intel® Core™ i3-6100TE (4M Cache, 2.7 GHz, 35W TDP)|Intel® Pentium® G4400TE (3M Cache, 2.4 GHz, 35W TDP)|Intel® Celeron® G3900TE (2M Cache, 2.3 GHz, 35W TDP)
GraphicsIntegrated Intel®HD graphics 530 or 510 (CPU dependent)
MemoryUp to 32 GB DDR4-2133 SDRAM by two SODIMM sockets
ChipsetIntel®Q170 platform controller hub
AMTSupports AMT 11.0
Video Port1x stacked VGA + DVI-D connector|2x DisplayPort connectors, supporting 4K/2K resolution
Audio1x Mic-in and 1x Speaker-out
SATA HDD2x internal SATA port for 2.5" HDD/ SSD installation, supporting RAID 0/1
mSATA1x full-size mSATA port (mux with mini-PCIe)
DC Input1x 3-pin pluggable terminal block for 8~35VDC DC input
Dimension240 mm (W) x 225 mm (D) x 111 mm (H)
MountingWall-mount by mounting bracket (standard) or DIN-Rail mounting (optional)
Operating Temperaturewith i7-6700, i5-6500, i3-6100 (65W/51W TDP)|-25°C ~ 70°C (configured as 35W CPU mode)|-25°C ~ 50°C (configured as 65W/51W CPU mode)
Storage Temperature-40°C ~ 85°C
Humidity10%~90%, non-condensing
VibrationOperating, 5 Grms, 5-500 Hz, 3 Axes(w/ SSD, according to IEC60068-2-64)
ShockOperating, 50 Grms, half-sine 11 ms duration (w/ SSD, according to IEC60068-2-27)
EMCCE/ FCC Class A, according to EN55022, EN55024 & EN55032
CPU Cores4
CPU FamilyIntel Celeron, Intel Core, Intel Pentium
Base CPU Speed2.1 to 3.0 GHz, 3.1 to 3.5 GHz
Video OutputDisplay Port, DVI-D, VGA
LAN Ports5-8
Serial Ports3-4
USB 2.05-6
USB 3.03-4
Max Memory32 GB
Operating SystemWindows 7, Windows 10, Linux
Effective Memory Speed2400 MHz
Form FactorFanless
Native Storage Type2.5" SSD, mSATA Full
On/IgnitionRemote On/Off
