15" Fanless Panel PC with Intel® Celeron® N2930 Processor

PPC-3150S-RAU

Starting at $1,070.00

Main Features:

  • 15" TFT XGA LCD with resistive touchscreen
  • Embedded Intel Atom Quad-Core E3845 1.91G
  • Wide operating temp. range from -20~60 C
  • Built-in one PCI or one PCIe x1 expansion slot
  • Wide range power input for 9~32VDC
  • Supports one internal 2.5" SATA HDD, one mSATA socket
  • One isolated RS-422/485 with Autoflow, Dual Intel GbE
  • One optional GPIO (8 channels, TTL level)
  • Fanless and Slim design
PDF Document - PPC-3150S-RAU Datasheet
PPC-3150S-RAU Datasheet
(Size: 495.4 KB)
PDF Document - PPC-3150S-RAU User Manual
PPC-3150S-RAU User Manual
(Size: 2.6 MB)
PDF Document - Data Sheet 3150S
Data Sheet 3150S
(Size: 765.9 KB)

System Configuration


* Selection required

PPC-3150-RE4BU
Your Configuration
PPC-3150S-RAU 15" Fanless Panel PC with Intel® Celeron® N2930 Processor
15" Fanless Panel PC with Intel® Celeron® N2930 Processor

In stock

Add to Favorites

$1,070.00

Don't see the exact configuration? Contact us, chat with us or give us a call 866-412-6278

PDF Document - PPC-3150S-RAU Datasheet
PPC-3150S-RAU Datasheet
(Size: 495.4 KB)
PDF Document - PPC-3150S-RAU User Manual
PPC-3150S-RAU User Manual
(Size: 2.6 MB)
PDF Document - Data Sheet 3150S
Data Sheet 3150S
(Size: 765.9 KB)
Specifications
ManufacturerAdvantech
ProcessorIntel Celeron N2930
Ethernet StandardI211-AT
SATA1x 2.5” SATA bay for storage
mSATA1x mSATA bay for storage
2.5" Drive1x 2.5” SATA bay for storage
Power Adapter90W recommended
Power TypeDC
Touchscreen Interface5 wire resitive touch
Vibrationsee manual
CPU Cores4
CPU FamilyIntel Celeron
Base CPU SpeedUnder 2.0 Ghz
Brightness400+ nit
Resolution1024 x 768
Screen Size10.1-15"
LAN Ports1-4
Serial Ports1-2
USB 2.01-2
USB 3.01-2
Max Memory8 GB
Operating SystemWindows 7, Windows 10, Linux
Effective Memory Speed< 1600 HHz
Form FactorPanel PC
Native Storage Type2.5" SSD, mSATA Full
MountingVesa Wall
Memory1x DDR3L 1333MHz SODIMM
Display Type15" TFT LCD (LED Backlight)
Display Size15"
Max Resolution1024 x 768
Luminance400
Viewing Angle80 (left), 80 (right), 70 (up), 70 (down)
Backlight Lifetime50,000 hrs
Contrast Ratio700
Light Transmission80+-5% at 550nm wavelength
Humidity10-95% @ 40C non condensing
Operating Temperature0-50C with SSD 0-40C with HDD
Storage Temperature-40-60C
Shocksee manual
EMCCE, FCC Class B. BSMI
Weight4Kg unboxed
Dimension391.36 x 312.46 x 51.5mm
