Nuvo-2610VTC: Intel Elkhart Lake Atom x6425E In-Vehicle Computer with 4x M12 PoE+ ports and 15mm 2.5” HDD/SSD support
Nuvo-2610VTCStarting at $985.00
- Intel Elkhart Lake Atom x6425E quad-core 2.0GHz/ 3.0GHz 12W processor
- Rugged -40°C to 70°C fanless operation, compliant with EN 50155 Class OT4
- 4x PoE+ GbE ports via M12 x-coded connectors
- 1x front-accessible 2.5” 15mm HDD tray and 1x M.2 2280 SATA SSD
- 1x M.2 3042/3052 B Key for 4G/5G mobile broadband
- 2x full-size mini-PCIe sockets for WIFI/CAN/GNSS modules
- 8-35V wide-range DC input with built-in ignition power control
Frequently Asked Questions
The front panel offers 1x USB 3.2 Gen1 (5 Gbps) port and 2x USB 2.0 ports, both with screw-lock mechanisms, a 3.5 mm 4-pole audio jack, and a DVI-I port supporting DVI and VGA output up to 1920 x 1080. Serial connectivity includes 1x isolated RS-485 port (COM1) with 15 kV ESD protection, and COM2/3/4 which can be configured as three 3-wire RS-232 ports or a single RS-422/485 port. The rear panel has four M12 X-coded Gigabit PoE+ ports (IEEE 802.3at, up to 25.5W each), a 15-pin isolated DIO port (4-CH DI, 4-CH DO), a 3-pin DC/ignition input terminal block, and a 3-pin remote on/off terminal block.
The system accepts a wide-range DC input of 8V to 35V via a 3-pin pluggable terminal block, which also carries the ignition (IGN) signal. Supplying more than 35V will damage the system. Maximum power consumption is 32W @ 35V under 100% CPU loading (12W CPU, 16GB RAM, 256GB SATA SSD), or 135W @ 35V when all four PoE+ ports are fully loaded at 25.5W each.
The Nuvo-2610VTC operates from -40°C to 70°C (EN50155 Class OT4) and can be stored from -40°C to 85°C, with 10%~90% non-condensing humidity. Note that for sub-zero or over 60°C operation, a wide-temperature HDD or SSD is required. It is rated for MIL-STD-810G vibration (Method 514.7, Category 4) and shock (Method 516.7, Procedure I), IEC61373:2010 Category 1 Class B Body Mounted vibration/shock (part of EN 50155), EMC per EN 50155:2017 Clause 13.4.8, and CE/FCC Class A per EN 55032 & EN 55035.
The system supports up to 32GB of DDR4-3200 SDRAM via one SO-DIMM socket. For storage, it has one internal M.2 2280 M-key slot (SATA signal only) for an M.2 SATA SSD, plus one front-accessible 2.5" HDD/SSD tray supporting drives up to 15mm in height and up to 5TB capacity.
The system provides two full-size mini-PCIe sockets: one with PCIe and USB 2.0 signal (for WiFi, GNSS, CAN, or similar modules) and one with USB 2.0 signal only (for WiFi modules). It also has one M.2 3042/3052 B-key socket (USB 3.1 + USB 2.0) for a 4G/5G mobile broadband module, with dual internal micro-SIM sockets. Antenna openings are available on the front and rear panels for these modules.
Due to Intel's driver policy, the system officially supports Windows 10 64-bit (Professional and IoT Enterprise editions). For Linux, kernel versions up to 5.8 are supported, with Ubuntu 20.04.2 LTS tested. On Linux, the Intel I210 GbE controller driver may need to be manually compiled if not already included in the kernel. A separate WDT_DIO driver package (v2.3.1.8 or later) is required for Watchdog Timer and DIO API functions.
The Nuvo-2610VTC measures 205 mm (W) x 156 mm (D) x 58 mm (H) and weighs 1.9 kg. It ships standard with a damping bracket, with an optional wall-mount bracket also available.
The Nuvo-2610VTC is the base model. The Nuvo-2611VTC adds an embedded SuperCAP UPS (2500 watt-second backup capacity) to sustain the system for a proper shutdown during power interruptions, and is taller (86.15 mm) and heavier (2.5 kg). The Nuvo-2612VTC includes a Cassette module providing an additional PCIe x4 Gen3 (2-lane) slot for an add-on card such as an AI accelerator module, and also has the same SuperCAP-style backup capacity (2500 watt-second) and 86.15 mm height, weighing 2.3 kg.
The system has four Gigabit PoE+ ports via M12 X-coded connectors, implemented using an Intel I210 controller. Each port is compliant with IEEE 802.3at and can deliver up to 25.5W to a powered device. One port (indicated in green) supports Wake-on-LAN.
How-to Guides
- Disassemble the system enclosure as described in the disassembly procedure (power off, disconnect all cables/antennae, remove the Cassette module if applicable, remove rear/front panel screws, and slide off the bottom panel).
- Remove the screws securing the heatsink and remove the heatsink to expose the SO-DIMM slot on the motherboard.
- Insert the gold fingers of the memory module into the slot at a 45-degree angle.
- Push down on the edge of the module until the side clips engage and secure the module in place.
- Reinstall the heatsink, enclosure, and panels when finished.
- Disassemble the system enclosure per the disassembly procedure.
- Remove the screws securing the heatsink covering the M.2 slot.
- Remove the heatsink to access the M.2 2280 (SATA-only) slot.
- Insert the M.2 SSD module into the slot at a 45-degree angle.
- Gently press the module down and secure it with the M3 P-head screw provided.
- Reinstall the heatsink and enclosure/bottom panel when done.
- Place the system on a flat, sturdy surface and turn the thumb screws on the front-accessible tray anti-clockwise to release it.
- Gently pull out the 2.5" HDD/SSD tray.
- With the HDD/SSD label facing downward, secure the drive to the tray using the screws provided (two screws on each side).
- Insert the tray back into the slot until resistance is felt.
- Tighten the thumb screws clockwise to secure the tray and complete the installation.
- Disassemble the system enclosure per the disassembly procedure to access the bottom panel.
- Remove the screws securing the heatsink covering the M.2 3042/3052 B-key slot and SIM card slots, then remove the heatsink.
- To install a micro-SIM card, slide the metallic cover in the indicated direction and lift it to expose the socket.
- Place the micro-SIM card into the socket in the correct orientation, lower the cover, and slide it closed to secure the card.
- Insert the M.2 3042/3052 module into the slot at a 45-degree angle and secure it with the provided screw.
- Reinstall the heatsink and enclosure/bottom panel when finished.
- Set the ignition control rotary switch on the motherboard to position 15 (0xF) to enable BIOS-configurable ignition parameters.
- Power on the system and press F2 to enter the BIOS setup menu.
- Navigate to [Power] > [Ignition Power Control].
- Configure the IGN Operation Mode (ATX, AUTO-ON, or IGN), Smart Off-Delay, BIOS POST Check, Power On Delay, Power Off Delay, Hard-off Timeout, Battery Voltage, and Low Battery Threshold according to your application.
- Press F10 to save changes and exit; the ignition control module will reset and operate per the configured parameters.
The Nuvo-2610VTC series is a rugged Intel Atom-based in-vehicle computer that incorporates four M12 Gigabit PoE+ connectors and one frontaccessible 2.5" HDD tray, supporting up to 15mm height HDD/SSD. It is designed to fulfill multi-purpose applications such as on-road, off-highway, or railway applications from mobile gateways, data loggers, to network video recorders (NVR).
Powered by Intel Elkhart Lake Atom x6425E quad-core CPU, the Nuvo-2610VTC series delivers 1.8x the CPU performance when compared with the previous generation. To provide robust Ethernet connectivity, the Nuvo-2610VTC series offers four Gigabit PoE+ ports via M12 x-coded connectors and two USB 3.1 ports with the screw-lock mechanism. In addition to the internal M.2 2280 SATA SSD for system storage, Nuvo-2610VTC also has one front-accessible 2.5" HDD tray accommodating a 2.5" SATA HDD/SSD with up to 15mm height and 5TB capacity. For internal expansion, it provides two mini-PCIe sockets for WiFi, GNSS, and CAN modules plus one M.2 3042/3052 B Key socket for 4G/5G mobile broadband module.
To meet versatile in-vehicle deployment conditions, the Nuvo-2610VTC series comes in three variants. In addition to Nuvo-2610VTC, the Nuvo2611VTC is equipped with an embedded SuperCAP UPS to withstand power interruptions or voltage fluctuations on the train and can sustain the system for a proper shutdown when the power is cut-off. The Nuvo-2612VTC has a Cassette module for an additional Gen3 x2 PCIe slot that can accommodate an AI accelerator module with a tailor-made thermal solution. With the AI accelerator, it becomes a fanless GPU computer for intelligent video analytics or a data logger with perception capability.
By integrating an Intel Atom quad-core x6425E, -40°C to 70°C fanless operations, wide-range DC input with ignition control, and 4G LTE / 5G NR mobile broadband connectivity, the Nuvo-2610VTC series is an ideal rugged, multi-purpose, in-vehicle computer for aftermarket on-road in-vehicle applications. With rugged M12 PoE+ connectivity and built-in SuperCAP UPS, the Nuvo-2610VTC series can withstand harsh and unstable electrical environments for off-highway applications such as trucks, cargo vehicles, and rolling stock.
| Manufacturer | Neousys |
|---|---|
| Short Description | The Nuvo-2610VTC series is a rugged Intel Atom-based in-vehicle computer that incorporates four M12 Gigabit PoE+ connectors and one front accessible 2.5" HDD tray, supporting up to 15mm height HDD/SSD. It is designed to fulfill multi-purpose applications such as on-road, off-highway, or railway applications from mobile gateways, data loggers, to network video recorders (NVR). |
| Processor | Intel Elkhart Lake Atom x6425E quad-core 2.0GHz/3.0GHz 12W processor |
| Graphics | Integrated Intel UHD Graphics |
| Memory | Up to 32 GB DDR4-3200 SDRAM by one SODIMM socket |
| PoE | 4x IEEE 802.3at (25.5W) Gigabit PoE+ ports by Intel® I210 via M12 x-coded connectors |
| Video Port | VGA and DVI dual display outputs via DVI-I connector |
| Audio | 1x 3.5 mm jack for mic-in and speaker-out |
| DIO | 4-CH isolated DI and 4-CH isolated DO |
| PCI Express | 1x PCIe x4 slot @Gen3, 2-lane PCIe signal in Cassette (Nuvo-2612VTC only) |
| M.2 | 1x M.2 2280 M key (SATA interface only) socket for SATA SSD installation |
| SATA HDD | 1x front-accessible HDD tray for 2.5" HDD/ SSD installation (up to 15mm height) |
| Remote Ctrl. & Status Output | 1x 3-pin pluggable terminal block for remote control and PWR LED output |
| Dimension | 205 mm (W) x 156 mm (D) x 58 mm (H) (Nuvo-2610VTC) 205 mm (W) x 156 mm (D) x 86 mm (H) (Nuvo-2612VTC) |
| Weight | 1.9 kg (Nuvo-2610VTC) 2.3 kg (Nuvo-2612VTC) |
| Mounting | Wall-mount (optional) |
| Operating Temperature | -40°C ~ 70°C*. EN50155 Class OT4 |
| Storage Temperature | -40°C ~85°C |
| Humidity | 10%~90% , non-condensing |
| Vibration | Operating, MIL-STD-810G, Method 514.7, Category 4 (pending) IEC61373:2010, Category 1, Class B Body Mounted (part of EN 50155) (pending) |
| Shock | Operating, MIL-STD-810G, Method 516.7, Procedure I (pending) IEC61373:2010, Category 1, Class B Body Mounted (part of EN 50155) (pending) |
| EMC | EN 50155:2017, Clause 13.4.8 (pending) CE/FCC Class A, according to EN 55032 & EN 55035 (pending) |
| CPU Cores | 4 |
| CPU Family | Intel Atom |
| Base CPU Speed | 2.1 to 3.0 GHz |
| Video Output | DVI-I, VGA |
| PoE Ports | 4 |
| Serial Ports | 3-4 |
| USB 2.0 | 1-2 |
| USB 3.1 | 1-4 |
| Max Memory | 32 GB |
| Operating System | Windows 10, Linux |
| Effective Memory Speed | 3200 MHz |
| Form Factor | Fanless |
| Native Storage Type | 2.5" SSD, M.2 SATA S80 |
| On/Ignition | Remote On/Off, Built In Ignition Control |
