POC-40+ Intel Elkhart Lake Atom x6413E Extreme-Compact Embedded Computer with 2x GbE and 2x USB 3.1

POC-40+ Series

Starting at $525.00

POC-40 Series is an extremely compact fanless computer with dimensions measuring just 52 x 89 x 112 mm. It features Elkhart Lake Atom processor and is designed for space-restricted applications such as factory data collection, rugged edge computing and mobile gateway.
  • Intel Elkhart Lake Atom x6413E processor
  • 52 x 89 x 112 mm extremely compact form factor
  • Rugged -25°C to 70°C fanless wide-temperature operation
  • Two GigE ports, two USB 3.1 Gen1 ports and two USB2.0 ports
  • M.2 2280 M key SATA storage interface
  • One M.2 B key socket supporting 5G/ 4G 3042/ 3052 modules
  • One M.2 E key socket for WiFi 5/ WiFi 6 modules
  • One COM port with RS-232/ 422/ 485 modes and three RS-232 COM ports
PDF Document - POC-40+ Data Sheet
POC-40+ Data Sheet
(Size: 479.5 KB)

System Configuration


* Selection required

Your Configuration
POC-40+ Intel Elkhart Lake Atom x6413E Extreme-Compact Embedded Computer with 2x GbE and 2x USB 3.1
POC-40+ Intel Elkhart Lake Atom x6413E Extreme-Compact Embedded Computer with 2x GbE and 2x USB 3.1

In stock

$525.00

Free Shipping Over $500

Don't see the exact configuration?

Contact us, chat with us, call 866-412-6278, or view shipping information.

POC-40 Series is an extremely compact fanless computer with dimensions measuring just 52 x 89 x 112 mm. It features Elkhart Lake Atom processor and is designed for space-restricted applications such as factory data collection, rugged edge computing and mobile gateway.

Utilizing Intel’s 10nm process technology, the new Elkhart Lake Atom® x6211E and x6413E processor can deliver up to 1.8 times the performance boost over its previous generation. In comparison to POC-200, POC-40 provides 1.9 times computing performance at only half the size. It features generic I/O functions, such as two Gigabit Ethernet ports, four USB 3.1 Gen1/ 2.0 ports, four COM ports and optional isolated digital I/Os for industrial communication and control. In addition, by adopting dedicated M.2 B key and E key slots, the POC-40 can fully harness the bandwidth of 5G and WiFi 6 wireless communications to provide wide-area coverage and real-time data transmission for industrial and mobile gateway applications.

With a similar footprint as a PICO-ITX motherboard, Neousys’ POC-40 is perfect for projects that require above par performance in an extremely compact package. Ideal for both edge computing and gateway applications, it is a low power consumption and lightweight fanless computer that offers wide-temperature operation for harsh environments.

PDF Document - POC-40+ Data Sheet
POC-40+ Data Sheet
(Size: 479.5 KB)
Specifications
Product Available OnSep 21, 2023
ManufacturerNeousys
Short Description POC-40 Series is an extremely compact fanless computer with dimensions measuring just 52 x 89 x 112 mm. It features Elkhart Lake Atom processor and is designed for space-restricted applications such as factory data collection, rugged edge computing and mobile gateway.
ProcessorIntel Atom x6413E quad-core 1.5GHz/ 3.0GHz 9W processor
GraphicsIntegrated Intel UHD Graphics
MemoryUp to 32 GB DDR4-3200 SDRAM (one SODIMM slot)
Video Port1x DisplayPort connector, supporting 4096 x 2160 resolution @ 60Hz
DIO4-ch isolated digital input and 4-ch isolated digital output
M.21x M.2 2280 M key SATA interface
Mini PCI-E1x full-size mini PCI Express socket with internal SIM socket
DC Input1x 4-pin pluggable terminal block for 12-20V DC input with optional ignition power control
Remote Ctrl. & Status Output1x 4-pin pluggable terminal block for remote control
Dimension52 mm (W) x 89 mm (D) x 112 mm (H)
Weight0.6 kg
MountingDIN-rail mount (standard) or Wall-mount (optional)
Operating Temperature-25°C ~ 60°C
Storage Temperature-40°C ~85°C
Humidity10%~90% , non-condensing
VibrationOperating, MIL-STD-810G, Method 514.6, Category 4
ShockOperating, MIL-STD-810G, Method 516.6, Procedure I, Table 516.6-II
EMCCE/FCC Class A, according to EN 55032 & EN 55024
