GPU / VPU Accelerated Computing

• Constant current LED lighting control
• 4-CH/2-CH LED Outputs
  • Up to 2A continuous output, max 180W rated
  • Up to 10A overriding output, max 500W peak
• 4-CH/2-CH isolated trigger inputs
• Support versatile operating modes:
  • continuous, pulsed, overdriving, and switched
• Support RS-232 and Ethernet interface
• 12-35V wide range DC input

Main Features:

•   Intel® 6th Generation Core™ i7/i5/i3 BGA type CPU with Intel QM170 PCH
•   I-Module expansion module
•   VGA & DVI Interface
•   1 x 2.5" HDD/ 1 x CFast slot/ 1 x mSATA storage options
•   2 Giga LAN and 8x USB 3.0
•   2 x RS-232/422/485 & 2 x RS232 Serial ports
•   Isolation COM module & 32bit GPIO module
•   Supports wide power range of 9 ~ 36V DC input
•   Supports wide range operating Temperature of -20° ~ 60° C
•   Supports SUSIAccess and Embedded Software APIs

Main Features:

• Intel® 8th Gen Core™ i CPU socket-type (LGA1151) with Intel® Q370/H370 chipset
• Wide operating temperature (-10°C ~ 50 °C)
• VGA and HDMI output
• 2 x GigaLAN, 2 x USB 3.1 and 6 x USB 3.0
• 2 x RS-232/422/485 and 4 x RS232 serial ports (Optional)
• 1 x 2.5" HDD/SSD, and 1 x mSATA
• 9V_DC ~ 36V_DC input power range
• Supports 2 x LAN, isolation COMs, and 32-bit GPIO modules
• Supports Advantech i-Modules
• Supports Advantech SUSIAccess and embedded software APIs

• Intel® 6th/7th Generation Core™ i Desktop CPU (LGA1151) with Q170/H110 chipset
• 2 x RS-232/422/485 and 4 x RS232 serial ports (with expansion cable)
• 1 x 2.5" HDD, 1 x CFast, 1x mSATA and 1 mini-PCIe with SIM
• Supports 2 LAN, Isolation COM, 32-bit GPIO modules
• 2 x GigaLAN and 8 x USB 3.0
• VGA and DVI output
• Supports Advantech's i-module, SUSIAccess, and embedded software APIs
• 9V_DC ~ 36V_DC input power range
• Wide operating temperature

Main Features:

• Intel Xeon Processor Broadwell-DE D-1539/D-1559 SoC CPU
• Wide operating temperature (-20 ~ 50 C)
• 9 ~ 36V DC input power range
• 2 x RS-232/422/485 and 4 x RS232 serial ports (with expansion cable)
• 1 x 2.5" HDD, 1 x CFast, 1 x M.2
• Support full range of i-module
• 4 x GigaLAN and 4 x USB 3.0
• Supports Advantech

Main Features:

• Patent-pending thermal design to allow -25°C to 60°C wide temperature system operation
• Includes 6th-Gen Intel Core i7 or i5 LGA1151 CPU
• 6x GigE ports, supporting 9.5 KB jumbo frame
• Up to 32 GB, DDR4-2133 SODIMM
• 240 mm x 225 mm x 111 mm compact footprint
• Compatible with MezIO interface for function expansion
• Accommodates two 2.5" SATA HDD/SSD with RAID 0/1 support

• Supports NVIDIA® GPU graphics card up to 120W TDP
• Patented thermal design to allow -25°C to 60°C wide temperature range operation
• Intel® 8th-Gen Core™ hexa-core 35W/65W LGA1151 CPU
• 6x GigE ports, supporting 9.5KB jumbo frame
• M.2 2280 M key socket (Gen3 x4) supporting NVMe SSD or Intel® Optane™ memory
• 4x USB 3.1 Gen2 ports and 4x USB 3.1 Gen1 ports
• Accommodates two 2.5" SATA HDD/ SSD with RAID 0/1 support
• Compatible with MezIO™ interface for function expansion
• Patented ventilation design for graphics card

Main Features

• Supports NVIDIA® Tesla P4/ T4 GPU
• Dedicated heat dissipation for -25°C to 60°C wide-temperature range operation
• Intel® 8th-Gen Core™ hexa-core 35W/ 65W LGA1151 CPU
• 6x GigE ports, 802.3at
• M.2 2280 M key NVMe (Gen3 x4) socket for fast storage access
• 4x USB 3.1 Gen2 ports and 4x USB 3.1 Gen1 ports
• Accommodates two 2.5" SATA HDD/SSD with RAID 0/1 support
• MezIO™ interface for easy function expansion

Main Features:

• Supports 9th/8th Gen core i7/i5/i3 LGA 1151 CPU
• Two x16 PCIe, two x8 PCIe, and three PCI slots
• Supports single NVIDIA GPU card with up top 180W TDP
• 8-CH isolated DI and 8-CH isolated DO
• 2x GbE ports with screw-lock
• 4x USB 3.1 Gen2 and 4x USB 3.1 Gen1 ports with screw-lock
• Two front accessible, hot-swappable 2.5" SATA HDD/SDD with RAID 0/1
• M.2 2280 M key NVMe (Gen3 x4) for fast storage access

Main Features:

• Supports 250W NVIDIA® graphics card up to 14 TFLOPS in FP32
• Supports Intel® Xeon® E or 8th/ 9th-Gen Core™ i7/ i5 LGA1151 CPU
• Up to 128GB ECC/ non-ECC DDR4 2133 (4x SODIMM)
• One x 16 (8-lanes), two x 8 (4-lanes), Gen3 PCIe slots for add-on cards
• 2 x M.2 B key and 3 x full-size mini-PCIe sockets
• 8~35V wide-range DC input with built-in ignition power control
• Patented thermal design for -25°C to 60°C rugged operation
• Patented damping brackets to withstand 1 Grms vibration

Main Features:

• Supports dual 250W NVIDIA® graphics cards up to 28 TFLOPS in FP32
• Supports Intel® Xeon® E or 8th-Gen Core™ i7/i5 LGA1151 CPU
• Up to 128GB ECC/non-ECC DDR4 2133 (4x SODIMM)
• Two x8, one x4, Gen3 PCIe slots for add-on cards
• Two hot-swappable 2.5” SATA HDD/ SSD with RAID 0/ 1 support
• 8~35V wide-range DC input with built-in ignition power control
• Patented thermal design for -25°C to 60°C rugged operation
• Patented damping brackets to withstand 1 Grms vibration

Main Features:

• Supports dual NVIDIA® Tesla T4 GPU
• Supports Intel® Xeon® E or 9th/ 8th-Gen Core™ i7/ i5 LGA1151 CPU
• Up to 128GB ECC/ non-ECC DDR4 2133 (4x SODIMM)
• Two x8 (4-lanes), Gen3 PCIe slots for add-on cards
• 1x M.2 M key, 1x M.2 B key and 2x full-size mini-PCIe sockets
• 8~48V wide-range DC input with built-in ignition power control
• Proven thermal design for -25°C to 60°C rugged operation*
• Patented damping brackets* to withstand 3 Grms vibration

• AMD Ryzen™ embedded V1000 series quad-core 15W/ 45W CPU
• -25°C to 70°C rugged wide-temperature operation
• Four Gigabit PoE+ ports with screw-lock
• Four USB 3.0 ports with screw-lock
• M.2 2280 M key NVMe (Gen3 x2) socket for fast storage access
• DP + VGA dual display outputs
• Front I/O access and DIN-rail mounting design
• MezIO™ compatible

Main Features:

• AMD Ryzen™ embedded V1605B quad-core 15W CPU
• -40°C to 70°C rugged wide temperature fanless operation
• Four IEEE 802.3at PoE+ ports with screw-lock
• One isolated CAN bus port for in-vehicle communication
• One M.2 socket and three mPCIe sockets
• M.2 2280 M key NVMe (Gen3 x2) socket for fast storage access
• 4-CH isolated DI and 4-CH isolated DO
• 8~35V DC input with built-in ignition power control
• E-Mark and EN 50155/ EN 45545 certificate
